(3) Holding Register (Set Data)
(1)
Time setting value
This is a set of four registers used by the DCS to set the device clock. When the time
setting request coil (address 00003 for GC1000 Mark II and GCIU, 00001 for the
analyzer server) is activated, these entries are used for the year, month/day, hour and
minute/second. Since all devices on the highway synchronize to the analyzer server
clock on a regular basis, the analyzer server clock should be regularly set.
F0518.EPS
Minute
Second
Hour
Month
Day
Year
Example : September 25, 1996, 15:23:10
07CC (hexadecimal)
0919 (hexadecimal)
000F (hexadecimal)
170A (hexadecimal)
Figure 5.4
Time Register Configuration
(2)
Range setting command
This address allows the range of the component indicated by the specified stream
number and peak number to be changed on the GC1000 Mark II.
(3)
Analysis value
These addresses display the same data as the analysis value in the input resister,
however values cannot be written to theses addresses. Only these addresses
support real number (floating point) form.
