Port Configuration
Page 3-15
Figure 3-7 Port Configuration Menu for 10/100BaseTX modules
IntraChassis 9000 Basic Port Configuration MenuModule Type: (24-100TX)
Module: [1]
Port: [1]
1 8 9 16 17 24
======== ======== ========
Operating Status: +------- -------- --------
Auto Negotiation: ******** ******** ********
Link Speed/Duplex: Fhhhhhhh hhhhhhhh hhhhhhhh
Port Status: Enabled Link Status: Up (24-100TX)
Auto-Neg: Enabled [ABCD] Link Speed: 10Mbps (Half Duplex)
h Help for legends
t Toggle Port Status Enable/Disable
u Toggle Auto-Negotiation/Manual
l Toggle 10M/100M bps Link Speed
d Toggle Half/Full Duplex
o Modify Auto-Negotiation Advertisement
r Restart Auto-Negotiation
a Advanced Port Configuration
g Global Port Configuration
q Return to Previous Menu
Command>
