Configuring for Management
Page 2-13
1000BaseX Ports Cabling Procedures
Cabling requirements for the 2-port Gigabit Ethernet modules depend on
which type of GBIC interface has been installed. Use the following chart to
determine the cabling requirements for your GBIC.
Table 2-3 1000BaseX cabling requirements
Configuring for Management
To use the IntraChassis 9000 as a managed switch, it must be configured with
an IP address. This can be accomplished in one of two ways:
❑ automatically using BootP (default)
❑
manually via the unit’s Console port
Connecting To Cable Required
1000BaseSX GBIC Cables with SC-type fiber connectors: 62.5 micron multimode
fiber media up to 260 meters long, or 50 micron multimode fiber
media up to 525 meters long.
1000BaseLX Long
Haul GBIC Cables with SC-type fiber connectors: 10 micron single mode fiber
media up to 100 kilometers long.
1000BaseLX GBIC Cables with SC-type fiber connectors: 10 micron single mode fiber
media up to 3 kilometers long.
