LEDs
Page 1-11
LEDs
The following indicator lights are used on the various modules of the
IntraChassis 9000.
Table 1-4 LEDs and their meanings
LED Color and Meaning
Management Module
Power Green - Power is on when lit
Slot Control Center Green - upper row - For future functionality
Green - lower row - Module is installed in this slot.
Gigabit Switch (GBIC)
Power Green - Power is on when lit
Link Green - connection and link has been made.
24-port 10/100 Switch
Link/Speed Green - Link at 100Mbps Amber - Link at 10Mbps
Duplex/Activity Green -Full Duplex Amber - Half Duplex Blinking - Active
Power Module
Power Green - Power is available to IntraChassis 9000
P-Fail Amber - Power is not available to module
Fail Amber - Power module is not delivering power
