Front Panel Button
Page 6-3
❑
SNMP (Simple Network Management Protocol)
❑
Addr Table (IP/MAC Address Table)
❑
VLAN (Virtual LAN Configuration)
❑
Duplicate IP (Duplicate IP Trap Log)
The following sections describe and explain the pages that are displayed when
you click each of the buttons.
Front Panel Button
This button opens (or refreshes) the IntraChassis Web Browser Management
Page. This is the top-level or opening page. It contains the following elements.
Front Panel display
The front panel graphic displays the image of the connected switch, its LED
panel, and the active data ports.
The front panel LED display simulates the IntraChassis in real-time operating
mode. It approximates all switch activity as it occurs.
