FP-2500/FP-2600 Series User Manual 7-12
8) Connect the backlight's one (1) power
connector. Next, close the circuit board
and secure the rear case in place using
the attachement screws removed in steps
1), 2) and 3).
7) Insert the new backlight in the FP. Insert
the unit by sliding it in the direction shown
in step 6).
• Be sure not to pinch or cut any of the FP unit's internal wiring when
closing the case.
• If any of the attachment screws becomes misplaced, check to be sure
that they have not fallen inside the FP. If a screw has fallen inside the
FP, do not connect the unit’s power cord until it has been removed.
