System Configuration
PLC Ladder Monitor Operation Manual
1-4
•
1-to-1 connection (Ethernet connection)
•
1-to-n connection (When accessing the Ethernet connection by surpassing the network.)
•
1-to-n connection (Ethernet connection)
Display
HUB
CS1 series
Connection cable
Display
External
device
External
device
Up to 32 units
HUB
Display
External
device
Up to 32 units
External
Device
External
device
HUB
HUB
