WAFER-CV-D25501/N26001 3.5" Motherboard
Page 80
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
CPU_FAN1 Smart Fan Control [Auto Duty-Cycle Mode]
CPU Temperature 1 60
CPU Temperature 2 50
CPU Temperature 3 40
CPU Temperature 4 30
SYS_FAN1 Smart Fan Control [Auto Duty-Cycle Mode]
System Temperature 1 60
System Temperature 2 50
System Temperature 3 40
System Temperature 4 30
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 11: Smart Fan Mode Configuration
CPU_FAN1/SYS_FAN Smart Fan Control [Auto Duty-Cycle Mode]
Use the CPU_FAN1 or SYS_FAN1 Smart Fan Control option to configure the CPU or
System Smart Fan.
Auto
Duty-Cycle
Mode
D EFAULT The fan adjusts its speed using Auto Duty-Cycle
settings
Manual Duty
Mode
The fan spins at the speed set in Manual Duty
Mode settings
CPU/System Temperature n
Use the + or – key to change the fan CPU or System Temperature n value. Enter a
decimal number between 1 and 100.
5.3.8 Serial Port Console Redirection
The Serial Port Console Redirection menu (BIOS Menu 12) allows the console
redirection options to be configured. Console redirection allows users to maintain a
system remotely by re-directing keyboard input and text output through the serial port.
