WAFER-CV-D25501/N26001 3.5" Motherboard
Page 7
1.6 Technical Specifications
The WAFER-CV-D25501/N26001 technical specifications are listed below.
Specification/Model WAFER-CV-D25501 WAFER-CV-N26001
Form Factor 3.5”
System CPU Intel® Atom™ D2550 1.86 GHz Intel® Atom™ N2600 1.6 GHz
System Chipset Intel® NM10
Memory
One 1066 MHz DDR3/DDR3L (1.35V)
SO-DIMM support (up to 4 GB)
One 800 MHz DDR3/DDR3L (1.35V)
SO-DIMM support (up to 2 GB)
Graphics Engine
Intel® GMA 3650 with a 640 MHz
graphics core
Intel® GMA 3600 with a 400 MHz
graphics core
Dual display supported
One VGA
One LVDS1 is integrated in the Intel® Atom™ D2550/N2600 processor
One LVDS2 is driven by the Chrontel CH7511 DP to LVDS converter
24-bit single-channel LVDS1 with
up to 1440x900 resolution
18-bit single-channel LVDS1 with
up to 1366x768 resolution
Display
24-bit dual-channel LVDS2 with up
to 1920x1200 resolution
24-bit dual-channel LVDS2 with up
to 1600x1200 resolution
Ethernet
Dual Realtek RTL8111E PCIe GbE controller (LAN1 with ASF 2.0
support)
BIOS UEFI BIOS
Super I/O Controller Fintek F81866
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion
One full-size PCIe Mini card slot with mSATA support
One half-size PCIe Mini card slot
Audio Realtek ALC662 HD Audio codec
COM
Three RS-232 (one by external connector; two by on-board pin headers)
One RS-422/485 by internal 4-pin wafer connector
Digital I/O One 8-bit digital input/output connector (4-bit input/4-bit output)
