IMBA-Q870-i2 ATX Motherboard
Page 70
BIOS Options Configured USB Ports
USB SW2 Power
LAN2_USB2 (external USB 2.0 ports)
USB1 (internal USB 2.0 ports)
USB2 (internal USB 2.0 ports)
CN4 (internal USB 3.0 ports)
Table 4-4: BIOS Options and Configured USB Ports
Please refer to Section 5.4.1 for detailed information.
4.4 Internal Peripheral Device Connections
This section outlines the installation of peripheral devices to the onboard connectors.
4.4.1 SATA Drive Connection
The IMBA-Q870-i2 is shipped with two SATA drive cables. To connect the SATA drives to
the connectors, please follow the steps below.
Step 1: Locate the connectors. The locations of the SATA drive connectors are shown
in Chapter 3.
Step 2: Insert the cable connector. Insert the cable connector into the on-board SATA
drive connector. See Figure 4-16.
