IMBA-Q870-i2 ATX Motherboard
Page 109
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
PC Health Status
> Smart Fan Mode Configuration
CPU Temperature :+49 C
SYS Temperature :+26 C
CPU_FAN1 Speed :727 RPM
SYS_FAN1 Speed :N/A
CPU_CORE :+1.743 V
+5V :+5.142 V
+12V :+12.271 V
DDR :+1.507 V
+5VSB :+4.968 V
+3.3V :+3.369 V
+3.3VSB :+3.276 V
VBAT :+3.074 V
Smart FAN Configuration
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 14: iWDD H/W Monitor
Î PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
ƒ System Temperatures:
o CPU Temperature
o System Temperature
ƒ Fan Speeds:
o CPU Fan Speed
o System Fan Speed
ƒ Voltages:
o CPU_CORE
o +5V
o +12V
o DDR
o +5VSB
o +3.3V
o +3.3VSB
o VBAT
