3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the board.
Connector Type Label
Additional power connector 4-pin connector ATXPWR1
ATX power connector 24-pin connector ATX1
Battery connector Battery holder BAT1
Chassis intrusion connector 2-pin header CHASSIS1
CPU power connector 4-pin connector CPU12V1
Digital I/O connector 10-pin header DIO1
DisplayPort connector 19-pin box header DP1
EC debug connector 18-pin header CN3
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connectors (system) 3-pin wafer SYS_FAN1, SYS_FAN2
Front panel audio connector 10-pin header FRONT-PANEL1
Front panel connector 14-pin header F_PANEL1
iRIS module connector 204-pin SO-DIMM slot IPMI1
Keyboard and mouse connector 6-pin wafer KB_MS1
LAN1 LED connector 2-pin header LED_LAN1
LAN2 LED connector 2-pin header LED_LAN2
Memory card slot DIMM slot CHA_DIMM1, CHA_DIMM2,
CHB_DIMM1, CHB_DIMM2
mSATA card slot PCIe Mini socket CN2
Parallel port connector 26-pin box header LPT1
PCI slot PCI slot PCI1, PCI2, PCI3, PCI4
PCIe x1 slot PCIe x1 slot PCIEX1_1
PCIe x16 slot PCIe x16 slot PCIEX16_1
PCIe x4 slot with PCIe x1 signal PCIe x4 slot PCIEX4_1
