5.3.9.1 Serial Port n Configuration
Use the Serial Port n Configuration menu (BIOS Menu 12) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
Serial Port n Configuration
Serial Port [Enabled]
Device Settings IO=3F8h;IRQ=4
Change Settings
[Auto]
Enable or Disable Serial
Port (COM)
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
= - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 12: Serial Port n Configuration Menu
5.3.9.1.1 Serial Port 1 Configuration
Î Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Î
Disabled Disable the serial port
Î
Enabled D EFAULT Enable the serial port
Î Change Settings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt
address.
Î
Auto D EFAULT The serial port IO port address and interrupt address
are automatically detected.
Î
IO=3F8h;
IRQ=4
Serial Port I/O port address is 3F8h and the interrupt
address is IRQ4
