IMBA-Q870-i2 ATX Motherboard
Page 8
Specification/Model IMBA-Q870-i2
Display Ports One HDMI integrated in the Intel® Q87 (up to 2560x1600, 60Hz)
One DVI-D integrated in the Intel® Q87 (up to 2560x1600, 60Hz)
One VGA integrated in the Intel® Q87 (up to 1920x1200, 60Hz)
One internal DisplayPort integrated in the Intel® Q87 supports HDMI, LVDS,
VGA, DVI, DisplayPort (up to 3840x2160, 60Hz)
Ethernet Two RJ-45 GbE ports
Keyboard/Mouse One internal keyboard and mouse connector
One PS/2 keyboard and mouse connector
TPM One TPM connector via 20-pin header
Serial Ports One external RS-232 serial port
One RS-422/485 via internal wafer connector
Four RS-232 via internal box headers
USB ports Two external USB 3.0 ports on rear IO
Two internal USB 3.0 ports by pin headers
Four external USB 2.0 ports on rear IO
Four internal USB 2.0 ports by pin headers
Serial ATA Six SATA 6Gb/s connectors support RAID 0, 1, 5, 10
LAN LED Two 2-pin LAN active LED connectors
Environmental and Power Specifications
Power Supply ATX power supported
Power Consumption [email protected], [email protected] , [email protected], [email protected], [email protected]
(3.90GHz Intel® i7-4770K CPU with four 4GB 1333MHz DDR3 DIMMs)
Operating Temperature -20ºC ~ 60ºC/-4°F ~ 140°F
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 244 mm x 305 mm
Weight GW/NW 1200 g / 700 g
Table 1-1: IMBA-Q870-i2 Specifications
