PICOe-B650 Half-size PCIe CPU Card
Page 71
Î
IO=2C8h;
IRQ=3, 4
Serial Port I/O port address is 2C8h and the interrupt
address is IRQ3, 4
5.3.8 H/W Monitor
The H/W Monitor menu (BIOS Menu 12) contains the fan configuration submenus and
displays operating temperature, fan speeds and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+44 C
SYS Temperature :+32 C
CPU FAN Speed :1950 RPM
VCC3V :+3.328 V
V_core :+1.112 V
+1.05V :+1.040 V
VDDR :+1.632 V
VSB3V :+3.424 V
VBAT :+3.232 V
5VSB :+4.992 V
> FAN 1 Configuration
Smart FAN Configuration
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 12: H/W Monitor
Î PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
ƒ System Temperatures:
o CPU Temperature
o System Temperature
ƒ Fan Speed:
o CPU Fan Speed
ƒ Voltages:
