5.2 Main
The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.
The Main menu gives an overview of the basic system information.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
BIOS Information
BIOS Vendor
American Megatrends
Core Version 4.6.4.0 0.03
Compliency UEFI 2.0
Project Version B218AR09.ROM
Build Date 12/29/2011 17:06:33
Memory Information
Total Memory
2048 MB (DDR3 1333)
System Date
[Tue 03/04/2011]
System Time [15:10:27]
Access Level Administrator
Set the Date. Use Tab to
switch between Data
elements.
----------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 1: Main
Î System Overview
The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information
cannot be changed. The items shown in the system overview include:
ƒ BIOS Vendor: Installed BIOS vendor
ƒ Core Version: Current BIOS version
ƒ Project Version: the board version
ƒ Build Date: Date the current BIOS version was made
Î Memory Information
The Memory Information lists a brief summary of the on-board memory. The fields in
Memory Information cannot be changed.
ƒ Total Memory: Displays the auto-detected system memory size and type.
The System Overview field also has two user configurable fields:
