PICOe-B650 Half-size PCIe CPU Card
Page 7
Specification PICOe-B650
Ethernet Two RJ-45 GbE ports
Audio Supports 7.1 channel HD audio via optional IEI AC-KIT-888HD kit
Keyboard/Mouse One keyboard and mouse connector via internal 6-pin header
Serial Ports Two RS-232 serial ports via internal pin header
USB 2.0 ports Two external USB ports
Two USB ports via internal pin headers
Storage
Serial ATA One SATA 6Gb/s port
One SATA 3Gb/s port
Environmental and Power Specifications
Power Supply 5 V / 12 V, AT/ATX power support
Power Consumption [email protected], [email protected], [email protected], [email protected] (3.4GHz
Intel® Core™ i7-2600K with two 2GB 1333MHz DDR3 memory)
Operating Temperature -10
°C~60°C
Storage Temperature -20
°C~70°C
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 185 mm x 122 mm
Weight GW/NW 1000g/260g
Table 1-1: Technical Specifications
