PICOe-B650 Half-size PCIe CPU Card
Page 66
Î
Disable Disables SATA devices.
Î
IDE Mode D EFAULT Configures SATA devices as normal IDE device.
Î
AHCI Mode Configures SATA devices as AHCI device.
Î Serial-ATA Controller n
Use the Serial-ATA Controller option to configure the SATA controller.
Î
Disabled Disables the on-board SATA controller.
Î
Enhanced Configures the on-board SATA controller to be in
Enhanced mode. In this mode, IDE channels and SATA
channels are separated.
Î
Compatible Configures the on-board SATA controller to be in
compatible mode. In this mode, a SATA channel will
replace one of the IDE channels. This mode supports
up to 6 storage devices.
5.3.5 Intel TXT(LT) Configuration
Use the Intel TXT(LT) Configuration menu to configure Intel Trusted Execution
Technology support.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Intel Trusted Execution Technology Configuration
Intel TXT support only can be enabled/disabled if SMX
is enabled. VT and VT-d support must also be enabled prior
to TXT.
Secure Mode Extensons (SMX)
Enabled
Intel TXT(LT) Support
[Disabled]
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 8: Intel TXT(LT) Configuration
