PICOe-B650 Half-size PCIe CPU Card
Page 47
NOTE:
IEI has a wide range of backplanes available. Please contact your
PICOe-B650 vendor, reseller or an IEI sales representative at
[email protected] or visit the IEI website ( http://www.ieiworld.com.tw )
to find out more about the available chassis.
4.5.3 CPU Card Installation
To install the PICOe-B650 CPU card onto the backplane, carefully align the CPU card
interface connectors with the corresponding socket on the backplane. To do this, please
refer to the reference material that came with the backplane. Next, secure the CPU card to
the chassis. To do this, please refer to the reference material that came with the chassis.
4.6 Internal Peripheral Device Connections
This section outlines the installation of peripheral devices to the onboard connectors.
4.6.1 Dual RS-232 Cable with Slot Bracket
The dual RS-232 cable slot connector consists of two connectors attached to two
independent cables. Each cable is then attached to a D-sub 9 male connector that is
mounted onto a slot. To install the dual RS-232 cable, please follow the steps below.
Step 1: Locate the connectors. The locations of the RS-232 connectors are shown in
Chapter 3.
Step 2: Insert the cable connectors. Insert one connector into each serial port pin
headers. See Figure 4-10.
