PICOe-B650 Half-size PCIe CPU Card
Page 37
Before and during the installation of the PICOe-B650 DO NOT:
ƒ Remove any of the stickers on the PCB board. These stickers are required for
warranty validation.
ƒ Use the product before verifying all the cables and power connectors are
properly connected.
ƒ Allow screws to come in contact with the PCB circuit, connector pins, or its
components.
4.3 CPU and Memory Installation
WARNING:
Do not run the CPU without a heatsink and fan. Without the heatsink
and fan, the high temperatures can destroy the CPU and other
components. CPUs marked as fanless don't need the fan, but still need
adequate ventilation.
The CPU, CPU cooling kit and DIMM are the most critical components of the PICOe-B650.
If one of these component is not installed the PICOe-B650 cannot run.
4.3.1 Socket LGA1155 CPU Installation
WARNING:
CPUs are expensive and sensitive components. When installing the
CPU please be careful not to damage it in anyway. Make sure the CPU
is installed properly and ensure the correct cooling kit is properly
installed.
DO NOT touch the pins at the bottom of the CPU. When handling the
CPU, only hold it on the sides.
To install the CPU, follow the steps below.
