PICOe-B650 Half-size PCIe CPU Card
Page 6
1.5 Technical Specifications
PICOe-B650 technical specifications are listed in table below.
Specification PICOe-B650
Form Factor Half-size PCIe CPU Card
CPU Socket LGA1155 socket
CPU Options Intel® Core™ i7/i5/i3 quad-core/dual-core processor
Intel® Pentium®/Celeron® processor
System Chipset Intel® B65
Graphics Engine Intel® HD Graphics Gen 6 support for DX10.1 and OpenGL 3.0
Full MPEG2, VC1, AVC Decode
Memory One 204-pin SO-DIMM socket supports one 1333/1066 MHz DDR3
SDRAM SO-DIMM (system max. 8 GB)
LAN Dual Realtek RTL8111E PCIe GbE controllers, LAN1 supports ASF 2.0
BIOS UEFI BIOS
Super I/O Fintek F81866
Ethernet Controller Two Realtek RTL8111E PCIe GbE controllers
(LAN1 with ASF2.0 support)
Digital I/O 8-bit digital I/O (4-bit input, 4-bit output)
Watchdog Timer Software programmable supports 1~255 sec. system reset
SMBus One 4-pin wafer connector
I
2
C One 4-pin wafer connector
TPM One 20-pin header supports optional Infineon TPM module
Expansion
PCI PCI signal via golden finger
PCIe Four PCIe x1 via golden finger
I/O Interface Connectors
Display One VGA port (VGA integrated in Intel® B65)
