ECG Parameters
9650-001358-01 Rev. B
ZOLL X Series Configuration Manual
111
12-Lead Format
The 12-Lead Format parameter allows you to specify the print format of 12-Lead data.
The values for the 12-Lead Format parameter are:
Print 10s Ldll
The Print 10s Ldll parameter allows you to enable or disable the X Series unit printing 10
seconds of the Lead II waveform after printing a 12-Lead snapshot.
The values for the Print 10s Ldll parameter are:
12-Ld Frequency Response
The 12-Ld Frequency Response parameter allows you to specify the 12-Lead waveform
frequency response.
The values for the 12-Ld Frequency Response parameter are:
Diagnostic: frequency ranges are 0.05-150 Hz.
Filtered Diagnostic: frequency ranges are 0.25-40 Hz.
12-Ld Analysis Enabled
The 12-Ld Analysis Enabled parameter allows you to enable or disable the 12-Lead
Interpretive Analysis capability.
Note:
This parameter is available only if the 12-Lead Interpretive Analysis option has been
purchased.
The values for the 12-Ld Frequency Response parameter are:
Possible Values:
2x6, 3x4, 3x4 Cabrera
Default:
3x4
Possible Values:
On, Off
Default:
On
Possible Values:
Diagnostic, Filtered Diagnostic
Default:
Filtered Diagnostic
Possible Values:
On, Off
Default:
On
