20 Warner Electric • 800-825-9050 P-207 • 819-0516
SFC-1000 Clutch Coupling Bearing Mounted Drawing I-25598
Customer Shall Maintain:
1. Armature mounting shaft concentric with field and
rotor mounting shaft within .006 T.I.R.
2. Angular alignment of shafts within 1/2 degree.
Arm Shaft .750 – 2.687
Rotor Shaft .500 – 2.000
Static Torque 240 lb. ft.
Maximum Speed 2,500 rpm
Standard Voltage D.C. 6, 24, 90
All dimensions are nominal unless otherwise noted.
6.531
1.421
1.546
.937
.062
.562
1.375
.187
.437
1.250
2.562
Dia.
2.062
2.687
2.500
10.328
Max.
Dia.
6.000
Dia.
4.093
Dia.
5.890 Max.
Armature View
See page 28 for details on
Bushings.
Field View
Removable plug in ends for
1/2" conduit.
45°
7.687 .343
.350/.342
See page 28 for details
on Bushings.
3.750
.875
6.125
