18
Warner Electric • 800-825-9050
P-207
•
819-0516
SFC-825 Clutch Coupling Bearing Mounted
Drawing I-25574
Customer Shall Maintain:
1. Armature mounting shaft concentric with field and
rotor mounting shaft within .006 T.I.R.
2. Angular alignment of shafts within 1/2 degree.
Armature View
See page 28 for details on
Bushings.
Field View
Arm Shaft
.500 – 1.500
Rotor Shaft
.500 – 1.500
Static Torque
150 lb. ft.
Maximum Speed
3,600 rpm
Standard Voltage
D.C. 6, 24, 90
All dimensions are nominal unless otherwise noted.
5.656
.984
1.546
.156
.562
1.296
1.656
1.250
Reverse
Mounting
.187
4.250
Dia.
2.500
Dia.
1.250
1.765
8.656
Max.
Dia.
.062
4.468 Max.
4.562 Max.
Removable plug in ends
for 1/2" conduit.
45°
6.812
.343
.350/.342
See page 28 for details
on Bushings.
3.750
.875
5.000
