TRM-20 AND TRM-40 USER’S MANUAL

REV 1

3.15.2. Saving Test Results to a Test Record

After performing a test, the user is presented the option to save the test results to the unit’s
Flash EEPROM or to a USB Flash Drive. If the test results are not saved immediately after
performing a test, they will still remain in the working memory and can be saved later, as long
as a new test has not been performed and the unit has not been turned off. Follow the steps
below to save the test results from the working memory to a test record (the following
procedure can also be used to re-save a restored test record to a new memory location or to a
USB Flash Drive):

a. Perform a test or restore a test record to the working memory, and then start from the

“START-UP” menu:

Press the

[2]

key (SETUP).

b. The following screen will be displayed:

Press the

[3]

key (SAVE/RESTORE RECORD).

c. The following screen will be displayed:

NOTE

Option 5 (COPY TO THUMB DRIVE) will be listed only if a USB Flash drive is
connected to the Auto-Ohm.

Press the

[2]

key (SAVE RECORD).

1. RESTORE RECORD
2. SAVE RECORD
3. RECORD DIRECTORY
4. ERASE RECORD
5. COPY TO THUMB DRIVE

1. RECORD ID
2. PRINT RECORD
3. SAVE/RESTORE RECORD
4. SET TIME
5. SET LANGUAGE

1. RUN TEST
2. SETUP
3. USER DIAGNOSTICS

11/07/11

08:49:15

°C 72°F
