TRM-20 AND TRM-40 USER’S MANUAL REV 1
26
3.9 Performing a Resistance Test
a. Start from the “START-UP” menu:
Press the [1] key (RUN TEST).
b. The following screen will be displayed:
Press the [1] key (RESISTANCE TEST).
c. The following screen will be displayed:
Press the
[2]
key (NO).
d. The following screen will be displayed:
Press the
[1]
key (V1, V2 RES TEST) if you would like to perform a V1 & V2 test.
Press the [2] key (V1 ONLY RES TEST) if you would like to perform a V1 test only.
1. V1, V2 RES TEST
2. V1 ONLY RES TEST
LTC OR VTG REGULATOR?
1. YES
2. NO
1. RESISTANCE TEST
2. SPECIAL RES TEST
3. DYNAMIC LTC TEST
4. DEGAUSS WINDING
1. RUN TEST
2. SETUP
3. USER DIAGNOSTICS
11/01/11
09:06:21
22 °C 72°F
