Vanguard TRM-20_40 User Manual
Page 43

REV 1 TRM-20 AND TRM-40 USER’S MANUAL
39
Press the
[ENTER]
key to confirm the reference temperature setting.
NOTE
The TRM will calculate the equivalent resistance value at this new
temperature.
k. The following screen will be displayed:
Press any key to continue.
l. The following screen will be displayed:
Set the LTC or Voltage Regulator tap position to the position indicated on the screen. To
change tap positions, press and hold the
[RAISE]
or
[LOWER]
LTC control button on
the front panel. Release the button when the tap position has been set to the position
indicated on the screen. Press the
[START]
key.
m. The following screen will be displayed momentarily:
calibrating
please wait...
- V1 & V2 TEST -
40 AMP TEST
set tap to 3 lower
"START" to RUN TEST
OR
"STOP" TO ABORT
***** WARNING! *****
DANGEROUS FLASH-OVER
WILL OCCUR IF CABLES
ARE DISCONNECTED!
********************
