Vanguard TRM-20_40 User Manual
Page 33
REV 1 TRM-20 AND TRM-40 USER’S MANUAL
29
Press the
[ENTER]
key to confirm the reference temperature setting.
NOTE
The TRM will calculate the equivalent resistance value at this new
temperature.
i. The following warning screen will be displayed:
This warning is a reminder that the next sequence of test steps will run current through
the test load.
Press any key to continue.
j. The following screen will be displayed:
Press the
[START]
key to run the test.
k. The following screen will be displayed momentarily:
calibrating
please wait...
- V1 & V2 TEST -
10 amp test
"start" to run test
or
"stop" to abort
***** WARNING! *****
DANGEROUS FLASH-OVER
WILL OCCUR IF CABLES
ARE DISCONNECTED!
********************
