REV 1 TRM-20 AND TRM-40 USER’S MANUAL
57
d. The following screen will be displayed:
Press the [START] key.
e. The V1, V2, and test current (I) will be displayed as shown below:
Press the [STOP] key to end the test and return to the “START-UP” menu.
USER DIAGNOSTICS
V1 = 35.86 m V
V2 = 38.43 m V
I = 20.020 A
** XFMR ENERGIZED! **
- USER DIAG TEST -
"START" TO RUN TEST
OR
"STOP" TO ABORT
