Vanguard TRM-20_40 User Manual

Page 53

REV 1 TRM-20 AND TRM-40 USER’S MANUAL

m. The following screen will be displayed:

1. YES

Press the

[1]

key (YES) to save the test record. Continue to step m.

2. NO

Press the

[2]

key (NO) if you do not want to save the test record. The following

screen will be displayed:

Press the

[1]

key (DO NOT SAVE RECORD) if you do not want to save the record.

You will be returned to the “START-UP” menu.

Press the

[2]

key (SAVE RECORD) to save the record. Continue to step m.

n. The following screen will be displayed:

NOTES

• The record number is automatically assigned and incremented by the TRM.
• Once the test record has been saved, it can be recalled and printed (3.15.3

and 3.15.4 for further information). Figure 7 shows a typical Special Test
report printout.

Press any key to return to the “START-UP” menu.

record number 03
has been saved!

ARE YOU SURE?
DATA WILL BE LOST!
3. DO NOT SAVE RECORD
4. SAVE RECORD

SAVE THIS RECORD?
1. YES
2. NO
