3.11 Performing a Special Resistance Test
The Special Resistance Test is used to conduct a resistance test for a pre-defined period ranging
from 1 to 45 minutes. The resistance data is recorded at one minute intervals. Use the steps
below to perform a Special Resistance Test:
a. Start from the “START-UP” ” menu:
Press the [1] key (TEST XFMR).
b. The following screen will be displayed:
Press the
[2]
key (SPECIAL RES TEST).
c. The following screen will be displayed:
Press the
[1]
key (V1, V2 SPEC TEST) to perform a V1 & V2 special resistance test.
Continue to step d.
Press the
[2]
key (V1 ONLY SPEC TEST) to perform a V1 special resistance test.
1. V1, V2 SPEC TEST
2. V1 ONLY SPEC TEST
1. RESISTANCE TEST
2. SPECIAL RES TEST
3. DYNAMIC LTC TEST
4. DEGAUSS WINDING
1. RUN TEST
2. SETUP
3. USER DIAGNOSTICS
11/07/11
08:49:15
22 °C 72°F
