d. The following screen will be displayed

Type the number of taps the LTC or Voltage Regulator has using the alpha-numeric
keypad, and then press the

[ENTER]

key. We will enter “3” for our example.

e. The following screen will be displayed:

If the tap information is correct, press the

[1]

key (YES) and continue to step f.

If the tap information is incorrect, press the

[2]

key (NO) and return to step d.

f. The following screen will be displayed:

Press the

[1]

key (V1, V2 RES TEST) if you would like to perform a V1 & V2 test. Continue

to step g.

Press the

[2]

key (V1 ONLY RES TEST) if you would like to perform a V1 test only.

Continue to step g.

1. V1, V2 RES TEST
2. V1 ONLY REST TEST

3 LOWER, -N-, 3 RAISE

IS THIS CORRECT?
1.YES
2.NO

ENTER NUMBER OF RAISE
TAPS, NOT COUNTING
NEUTRAL (1-23):
