TRM-20 AND TRM-40 USER’S MANUAL REV 1
60
3.15 Working with Test Records
3.15.1. Viewing the Contents of the Working Memory
Whenever a test is performed and the reading is kept, the data is temporarily stored in the
TRM’s working memory. You can view the test reading in the unit’s working memory using the
steps below:
a. Start from the “START-UP” menu:
Press the
[2]
key (SETUP).
b. The following screen will be displayed:
Press the
[2]
key (PRINT RECORD).
c. The following screen will be displayed:
1. PRINT TO LCD
Press the
[1]
key (PRINT TO LCD) to view the test record on the LCD screen. Use
the
[PAPER ∨ Contrast]
key to scroll to the next page. Press the
[STOP]
key
when you are done viewing the test record, and you will be returned to the
“START-UP” menu.
PRINT RECORD
1. PRINT TO LCD
2. PRINT TO PRINTER
1. RECORD ID
2. PRINT RECORD
3. SAVE/RESTORE RECORD
4. SET TIME
5. SET LANGUAGE
1. RUN TEST
2. SETUP
3. USER DIAGNOSTICS
11/07/11
08:49:15
22 °C 72°F
