REV 1 TRM-20 AND TRM-40 USER’S MANUAL
31
Once the data is saved, the following screen will be displayed:
Press the [STOP] key to stop running the test. The test results will be displayed as
shown:
Press any key to continue.
m. The following screen will be displayed:
1. YES
Press the
[1]
key (YES) to print the test results on the built-in thermal printer. A
sample test results printout is shown in Figure 5. Continue to step n.
2. NO
Press the [2] key (NO) to bypass printing of the test results. Continue to step n.
PRINT TEST RESULTS?
1. YES
2. NO
TEST RESULTS
I = 10.01 AMPS
R1 = 1.465
m Ω
R2 = 1.448
m Ω
TEST IN PROGRESS 14
=== > TEST SAVED! < ===
I = 10.01 AMPS
R1 = 1.465
m Ω
R2 = 1.448
m Ω
** XFMR ENERGIZED! **
