Teledyne LeCroy Editing Generation Files with the Script Editor
68 Summit Z3‐16 PCI Express Multi‐Lane Exerciser User Manual
4.11.1 Script Editor Toolbar
The toolbar contains buttons for saving your edits, navigating, searching and other
functions.
Save. Saves your edits and
immediately updates the
setting bars and Frames
shown in the CATC Trace
window.
Go to Trace View.
Causes trace view to bring
the currently selected script
line to the top of the screen. Toggle Bookmark. Allows
markers to be set or
removed to aid in
navigation.
View Options. Opens a
menu with three options:
Enable Outlining
Toggle Outlining
Line Numbers.
See “View Options Menu”
on page 72
for descriptions.
Next Bookmark.
Cut. Previous Bookmark.
Copy. Clear All Bookmarks.
Paste. Find.
Undo. Replace. Find and replace.
Redo. Print.
