Summit Z3‐16 PCI Express Multi‐Lane Exerciser User Manual 61
Generation Options Dialogs Overview Teledyne LeCroy
Note:
In Device emulation mode, the current MaxPayload size set in configuration space will be used
by completions from both firmware memory space and FastCompleter.
Note: In Host emulation mode, the RCB set in generation options will be used by completions. Z3 will
follow the rules for aligning completion boundaries based on MaxPacket size (and RCB).
Address/
Offset (hex) 32‐bit
Address/
Offset
64‐bit
Address/
Offset 32‐bit
0x000000
00 If the corresponding Region is set, based on
the region type, this field is a
32‐bit Offset for Mem_32A and Mem_32B, 64‐
bit Offset for Mem_64,
32‐bit Address for Fixed_32, and
64‐bit Address for Fixed_64.
The corresponding Region must be set to
enable the Address/Offset.
Length 
(in 4‐KB
blocks) 0 to
1,048,576 0 If the corresponding Region is set, this field
specifies the length of the address range in 4‐
kilobyte blocks, starting from the address/
offset, in the Address/Offset field, to which
the fast memory completer responds.
The corresponding Region must be set to
enable Length.
PldGrowth Fixed Byte
Fixed
DWord
Incr Byte
Incr DWord Fixed Byte If the corresponding Region is set, this field
specifies the expected payload format.
Fixed Byte and Fixed DWord specify a payload
of a byte or dword pattern consisting of
PldSeed.
Incr Byte and Incr DWord specify a payload of
incrementing bytes or dwords starting from
zero.
The corresponding Region must be set to
enable PldGrowth.
PldSeed (hex) 8‐bit value
10‐bit value 0 If the corresponding Region is set and
PldGrowth is set to Fixed Byte or Fixed DWord,
this field species the byte value repeated for
PldGrowth of Fixed Byte or the 10‐bit dword
value for PldGrowth of Fixed DWord.
For other types of PldGrowth, this field is set
to zero.
The corresponding Region and PldGrowth
must be set to enable Pldseed.
