WPS-300-DVR-9CH & 16CH Installation and Users Manual
WPS-300-DVR-9CH Storage Size: 1000GB (1TB)
Resolution Quality
Total Recording Rate (FPS)*
480 240 180 120 60 30 15
720x480
(Full D1)
9 3.5 7.0 13.9 27.9
8 3.9 7.9 15.7 31.5
7 4.6 9.2 18.4 36.7
6 5.2 10.5 21.0 41.9
5 6.9 13.8 27.6 55
4 8.5 17.1 34.1 68
3 12.5 25.1 50 100
2 17.2 34.4 69 138
1 26.8 54 107 214
720x240
(Half D1)
9 3.5 4.6 6.9 13.9 27.8 56
8 3.9 5.2 7.8 15.7 31.4 63
7 4.6 6.1 9.2 18.4 36.7 73
6 5.2 7.0 10.5 21.0 41.9 84
5 6.9 9.2 13.8 27.6 55 110
4 8.5 11.3 16.9 33.8 68 135
3 12.4 16.5 24.7 49 99 198
2 17.2 23.0 34.4 69 138 276
1 26.8 35.7 54 107 214 429
360x240
(CIF)
9 3.4 6.9 9.2 13.8 27.6 55 110
8 3.9 7.8 10.4 15.6 31.1 62 124
7 4.6 9.3 12.4 18.5 37.1 74 148
6 5.2 10.5 14.0 21.0 41.9 84 168
5 6.9 13.8 18.4 27.6 55 110 220
4 8.3 16.6 22.2 33.3 67 133 266
3 12.1 24.1 32.2 48.2 96 193 386
2 17.2 34.4 45.9 69 138 276 551
1 26.8 54 71 107 214 429 857
* Time in Days is estimated based on typical camera scenes, and averaged by H.264 I/P/P frames.
