G) RS-422 Serial Port (on Card Cage)

(RJ-12 or RJ-45 Connector)

This is used for configuration, uploading and downloading configurations,

status enquiries, AutoDownloading show data to Flash memory, and serial
port RealTime updates. It is compatible with all the RS-422 Serial Ports and
protocols used on Gilderfluke & Company products.

The four active lines on this connector are bussed to the backplane of the

card cage. This allows you to communicate to a whole card cage full of Br-
ANAs, 'Smart' Brick Brains, Electronic FeedBack (EFB) 'Smart' Bricks and
other cards through the connector on the card cage. They just need to be
set to different addresses.

The serial data signals from the Br-ANA are brought out on a six position

RJ-12 (six position, six conductor modular telephone style connector) on the
card cage. Facing the end of the cable with the release latch upwards, its pin
out is as follows:

POSITION

WIRE #

COLOR

SIGNAL NAME:

LEFT

RIGHT

1

white

Signal Ground

2

black

- Serial data out from card

3

red

+ Serial data out from card

4

green

- Serial data in to card

5

yellow

+ Serial data in to card

6

blue

Ground

Computers donʼt normally come with serial ports on them anymore. In-

stead, you use a USB-to-Serial (

USB-RS232/422

or

C-USB-RS232

) adapter,

BlueTooth-to-Serial (

Bt-Rs232Rx

and

Bt-USBTx

), Ethernet-to-Serial

(

Modem-Internet

) adapter, or WiFi-to-Serial (

Modem-Wi-Fly

) adapter. For the

Br-ANA you will need one that provides a RS-422 connection, instead of the
more common RS-232. These are available from a number of different
sources, including Gilderfluke & Company. Our part number is

USB-RS232/

422

for the USB-to-Serial adapter. It provides both RS-232 and RS-422 con-

nections.

The Br-ANA expects to see the serial data in the following format:
