as a ʻSmartʼ Brick. The ʻSmartʼ Brick Network normally found on a ʻSmartʼ
Brick is brought out on the edge connector. When plugged into any
Gilderfluke & Co. Brick card cage, this will be brought out on a RJ-12 (or RJ-
45
5 ) connector on the card cage. There should never be both ʻSmartʼ and
ʻDumbʼ Bricks in the same card cage. They share the same pins on the edge
connector and backplane. Damage may result if both are installed in the
same card cage.
The ʻSmartʼ Brick Network signals to the Br-ANA are brought in through a
six position RJ-12 (six position, six conductor modular telephone style con-
nector) on the card cage. Facing either end of the cable with the release
latch upwards, its pin out is as follows:
POSITION WIRE # COLOR SIGNAL NAME:
LEFT
RIGHT
1 white Smart Brick Net Data +
2 black Smart Brick Net Data -
3 red Smart Brick Net Clock +
4 green Smart Brick Net Clock -
5 yellow Smart Brick Net Strobe +
6 blue Smart Brick Net Strobe -
E) ʻJ8ʼ Inputs (on Card Cage)
(RJ-12 or RJ-45 Connector)
If Switch #4 is in the ʻDumbʼ Brick position, the Br-ANA will be operating
as a ʻDumbʼ Brick. The trigger inputs and status output normally found on a
ʻDumbʼ Brick are brought out on the edge connector. When plugged into any
Gilderfluke & Co. Brick card cage, this will be brought out on a RJ-12 (or RJ-
45)
6 connector on the card cage. There should never be both ʻSmartʼ and
ʻDumbʼ Bricks in the same card cage. They share the same pins on the edge
connector and backplane. Damage may result if both are installed in the
same card cage.
Gilderfluke & Co.• 205 South Flower Street • Burbank, California 91502 • 818/840-9484 • 800/776-5972 • fax 818/840-9485
Br-ANA Manual / December 18, 2012 10:21 AM / page 20 of 60
5 If the card cage has a RJ-45 connector, just ignore the outer two wires. The center six wires are wired as shown for the RJ-12
connector.
6 If the card cage has a RJ-45 connector, just ignore the outer two wires. The center six wires are wired as shown for the RJ-12
connector.
