Br-ANA Connectors

A) Z-Brick

3

(One Twenty Pin IDS Header)

This connector is used to control one or more Z-Bricks. When enabled,

the Br-ANA outputs data from the DMX-512 input or onboard Flash Memory
to this connector. The format of the data is as follows:

IDS pin #

SIGNAL

1

Data bit 0

2

Data bit 1

3

Data bit 2

4

Data bit 3

5

Data bit 4

6

Data bit 5

7

Data bit 6

8

Data bit 7

9

Address bit 0

10

Address bit 1

11

Address bit 2

12

Address bit 3

13

Address bit 4

14

Address bit 5

15

Address bit 6

16

Address bit 7

17

ground

18

ground

19

Strobe/

20

Reset/

When the address and data lines are valid, the rising edge of the Strobe

line will latch the data into the addressed outputs.

Gilderfluke & Co.• 205 South Flower Street • Burbank, California 91502 • 818/840-9484 • 800/776-5972 • fax 818/840-9485

Br-ANA Manual / December 18, 2012 10:21 AM / page 15 of 60

3

The Z-Brick connector is a legacy connection. It is there just for backwards-compatibility on existing systems. It is highly recom-

mended that you do not use the Z-Brick connector for attaching Z-Bricks. Instead, just send DMX-512 to them just as you would for
any other GilderGear. The Z-Brick connector will likely not be installed unless specifically requested on new builds of Br-ANAs.
