Gilderfluke & Co.• 205 South Flower Street • Burbank, California 91502 • 818/840-9484 • 800/776-5972 • fax 818/840-9485

Br-ANA Manual / December 18, 2012 10:21 AM / page 6 of 60

A note about this manual:

This manual covers the specifics of the Br-ANA. To

program the Br-ANA you will also want to refer to the
PC•MACs manual sections that cover the PC•MACs
software.

The Br-ANA is typically programmed in ‘Software-only’

or ‘Hardwareless RealTime’ mode. If you are using the USB-
DMX
for programming your Br-ANA through the DMX-512
inputs, please refer to the PC•MACs ‘Unlimited’ mode.

The full PC•MACs manual can be downloaded from our

web site at:

http://www.gilderfluke.com
