Securitron iEXD-24 - Manual (Page 4)

PN# 500-18900
Page 4
Rev. D, 10/07
FUNCTION Nuisance Delay Release Delay Relocking Power
NFPA 101
(NATIONAL FIRE
PREVENTION
ASSOCIATION
LIFE SAFETY
CODE) Permitted, up to
3 seconds 15 seconds,
extendable to 30
seconds with
local approval “Manual”,
typically
via keyswitch Doors release when
DC power is cut.
Battery backup
acceptable when
approved by local
authority
SBC (STANDARD
BUILDING CODE)
Not allowed 15 seconds,
extendable to 30
seconds with
local approval
“Automatic”
when door is
used (via
doorswitch)
Doors release when
DC power is cut.
Battery backup
acceptable when
approved by local
authority
UBC (UNIFORM
BUILDING CODE) Required, fixed
at 2 seconds 15 seconds only “Manual”,
typically
via keyswitch
When power to
doors, smoke
detection or exit
illumination is cut,
doors must release.
Battery backup for
locks is excluded.
BOCA
(BUILDING
OFFICIALS;
CODE ADMINIS-
TRATORS)
Required, fixed
at 1 second 15 seconds,
extendable to 30
seconds with
local approval
Special,
complex
relocking
sequence:
see below
paragraph*
Doors release when
building power is
cut. Battery backup
not acceptable
NATIONAL
BUIDING CODE
OF CANADA Not allowed 15 seconds only “Manual”,
typically
via keyswitch Doors release when
building power is
cut. Battery backup
not acceptable
* BOCA RELOCKING: A special type of automatic timed relocking is required. After the release
delay expires, the lock releases. When the door is opened, the iMXD detects this but nothing
happens immediately (the lock remains released). When the door re-closes, a "relock delay" of
30 seconds begins. If the door is not opened again during this 30 second period, it will relock.
If it is opened again, the 30 second relock delay will begin again on door closure. The door will
only relock when it has been left undisturbed for 30 seconds after re-closure. The local authority
may extend the relock delay to 45 seconds for sensitive facilities. The standard iMXD control
board supports the BOCA 30 second relock sequence. If the 45 second relock sequence is
required, contact the factory to receive a modified board.
2.3. DIP SWITCH SETTING
Once you have determined the settings for nuisance delay, release delay, relocking (including
special BOCA relocking), dip switches on the iMXD control board may be set to select these
parameters. The factory set condition
of the board is nuisance delay 1 second,
15 second release delay and standard
(non BOCA) relocking via the internal
keyswitch. If you require a variation
from this configuration, some Dip
Switch settings will have to be altered.
Switch 1: This sets the amount of time
for release delay. In the factory set
(Off) position, release delay is set for 15
seconds. Turning the switch On sets a
30 second release delay.
Switch 2 and 3: The combined position of the 2 switches selects 4 different values for nuisance
delay.
DIP
SWITCHES
0N
OF
F
1
2
3
4
FACTORY SETTINGS SHOWN IN BLACK
BOCA RELOCKING STANDARD RELOCKING
MATRIX (SEE TEXT)
MATRIX (SEE TEXT) MATRIX (SEE TEXT)
MATRIX (SEE TEXT)
15 SEC. RELEASE DELAY 30 SEC. RELEASE DELAY
5 MANUAL RELOCKING AUTOMATIC RELOCKING
