GL1 QUICK START GUIDE
1) USE SUPPLIED TEMPLATE TO LOCATE AND INSTALL MOUNTING HARDWARE
2) CUT THRU GASKET FOR REAR WIRE HOLE ACCESS IF REQUIRED
3) INSTALL MOUNTING SCREWS - TOP CHASSIS HOLES ONLY!
4) WELD WITHIN PROVIDED CHASSIS SLOTS AND/OR STRIKE PLATE EDGES
5) ROUTE AND CONNECT WIRING - VERIFY OPERATION OF THE LOCK AT THIS POINT
6) INSTALL CAMLOCK AND PLUG IN COVER
7) INSTALL COVER OVER TOP AND SLIDE DOWN INTO POSITION
8) INSTALL COVER SCREWS
9) PLUG CONDUIT FITTING IF NOT USED, WELD PLUG FOR MAXIMUM SECURITY
IF YOU NEED ADDITIONAL HELP REFER
TO TROUBLESHOOTING GUIDE ON
PAGES 14-15 OF "INSTALLATION AND
OPERATING INSTRUCTIONS"
