Magnalock, Preparation 1 – Securitron M680BDCX User Manual
Page 3
PN# 500-10560
Page 3
Rev. D, 07/12
Magnalock
Preparation
1.
Using a Phillips screwdriver, remove the two (2) screws securing the cover as shown.
Remove the cover to provide access to the circuit board on the back of the magnet.
The screws should be saved to re-attach the cover later.
2.
Component Locations
SW2
Quick Clip 1:
BDCX
Configuration
