Operator's Manual
Rivers Edge® One-Man Ladder Stands
BOlT IDENTIfICATION ChART
Not all bolt sizes shown are included with all treestands. Bolts shown
are for size reference only. Extra hardware may be included in the
parts bag.
1/4-20 x 1-1/4" grade 5 hex head bolt
1/4-20 x 1-1/2" grade 5 hex head bolt
1/4-20 x 1-3/4" grade 5 hex head bolt
1/4-20 x 2" grade 5 hex head bolt
1/4-20 x 2-1/4" grade 5 hex head bolt
1/4-20 x 2-1/2" grade 5 hex head bolt
1/4-20 x 2-3/4" grade 5 hex head bolt
5/16-18 x 2-1/2" grade 5 hex head bolt
5/16-18 x 3-1/4" grade 5 hex head bolt
1/4-20 x 3" grade 5 hex head bolt
1/4-20 x 3-1/4" grade 5 hex head bolt
5/16-18 x 1-3/4" grade 5 hex head bolt
5/16-18 x 2" grade 5 hex head bolt
5/16-18 x 2-1/4" grade 5 hex head bolt
1/4-20 x 2-1/4" grade 5 Phillips head bolt
