Operator's Manual
Rivers Edge® One-Man Ladder Stands
kEY # PART #
DEsCRIPTION
QTY.
1
1ML23
TUBE, STABILZIER, SUPPORT
1
2
1ML40
BRACE, SUPPORT FLAT
2
3
2ML130
WELDMENT, TREE BLADE
1
4
410079
STRIP FABRIC MOUNT
1
5
48250B
BOLT 1/4-20 X 1-3/4" HHCS
GR5 BLK ZN
4
6
63281
SNAP PIN, 1/4 X 1-3/4",
ROUNDED RETAINER
8
7
410000
WELDMENT PLATFORM 29" X 18.25"
2
8
410003
J PIPE LADDER
2
9
410004
WELDMENT TREE BLADE
1
10
410005
WELDMENT UPRIGHT SEAT
2
11
410008
BRACKET SEAT PIVOT
2
12
410009
ARMREST
2
13
410010
STRIP FABRIC MOUNT
1
14
410011
WELDMENT DOOR MOUNT
2
15
410017
LOOP DOOR
2
16
410018
TUBE SIDE CURTAIN RAIL
2
17
410019
UPRIGHT CURTAIN RAIL
2
18
410020
J PIPE CURTAIN RAIL
2
19
410023
LOOP SEAT UPRIGHT
1
20
410024
BRACE SUPPORT 35.69"
2
21
410025
WELDMENT LADDER 3 STEP 46"
1
22
410027
WELDMENT LADDER 3 STEP
W/VAM 46"
1
23
410028
WELDMENT LADDER 3 STEP W/HOLES
43.25"
1
24
410071
WELDMENT FTS SEAT FRAME
1
25
410077
RAIL FABRIC MOUNT FLIP SEAT
2
26
48153B
BOLT 1/4-20 X 2" HHCS GR5 BLK ZN
14
27
48240B
BOLT 1/4-20 X 1-1/2" HHCS GR5 BLK ZN
22
28
48261B
WASHER FLAT 1/4" BLACK
45
29
48271B
BOLT 1/4-20 X 2-1/4" HHCS GR5 BLK ZN
18
30
8909B
BOLT 1/4-20 X 1-1/4" HHCS GR5 BLK ZN
6
31
L17
WELDMENT, STABILIZER BAR
1
32
WN516
WASHER, 5/16", BLACK NyLON
4
33
48752B
NUT, FLANGED, NyLOCK, 1/4-20
66
34
48270B
BOLT 1/4-20 X 2-1/2 HHCS GR5 BLK ZN
2
NO EXTENsIONs AvAIlABlE fOR ThIs MODEl.
NEvER MODIfY OR EXCEED ORIGINAl sTATED usE hEIGhT!
PART #
DEsCRIPTION
QTY.
360005
PADDED SEAT
1
48736
9" CAMO PAD
2
48155
HARNESS FAS, W/SRD
1
48415
RATCHET STRAP
3
48691
TIE-OFF ROPE KIT
1
410103
ARMREST STRAP
2
48218
CABLE, 15"
2
360002
PAD BUMPER 12"
6
360000L
CURTAIN SEWN LEFT
1
360000R
CURTAIN SEWN RIGHT
1
360020
ASSEMBLy SEAT OPENING DAy
1
360024
ASSEMBLy BACKREST OPENING DAy
1
48800
DVD TREESTAND SAFETy
1
ITEMs NOT shOWN:
Maximum height - 15' to shooting rail
Maximum field Rating - 300 lbs.
Tree Diameter Range - 12" to 20"
lADDER PARTs lIsT (RE624)
