Check for parts online at

www.huntriversedge.com or call 800-450-EDGE (3343) M-F 8-5

33

Operator's Manual

Rivers Edge® One-Man Ladder Stands

sETuP AND usE INsTRuCTIONs

(fOR All lADDER sTANDs IN ThIs MANuAl)

During installation and removal of ladder treestands, you must

always and properly use the included Full Body Harness (Fall Arrest

System). Refer to the Full Body Harness instructions included with

this product for proper use.

1. With assembled product lying on the ground in assembled position,

position one person at bottom end of ladder lying on the ground.

This person has to prevent the ladder end from tilting up when platform

end is lifted and prevent the ladder from skidding across ground.

2. a. Position (2) people at the platform end of the ladder, lift the

platform end, and continue uprighting by walking toward bottom

end of ladder and moving hands along ladder legs. stand ladder

up against chosen straight tree on dry, level ground. Use caution

when ladder comes over center against tree.

b. Step back and look at ladder top to see that it is level. Adjust as

needed to achieve a level platform at top. For ladder stands with

two tree blades (one at platform level and one at upper level) be

sure that both tree blades are contacting tree. Adjust as needed so

both tree blades are contacting tree.

c. Step down hard on bottom step to push ladder legs into the

ground.

d.

(fOR RE607, RE623, RE624 ONlY) With ratchet strap now in

hand, hook “S” hook with long strap to the stabilizer bar link welded

on stabilizer bar. Feed the long strap through the center (slot) of

ratcheting mechanism and back around through tightening lever.

sEE fIGuREs 1 AND 2. Secure the ladder tight so the stabilizer bar

is at a right angle to the tree. Adjust stabilizer bar length as necessary

so it contacts tree. Be absolutely sure the tree blade(s) at top and the

stabilizer bar are all contacting tree.

notE: Be sure you feed the long strap correctly so there are no

twists in the strap.

Wrap entire ratchet assembly around tree and hook other “S” hook

through opposite side of stabilizer bar link. Pull tail of long strap until

most of the slack is taken out. Be sure entire strap is even and at the

same level all around tree. "Ratchet" tight to tree, this will securely

attach stabilizer bar to tree. sEE fIGuRE 1. Be absolutely sure the

tree blade(s) at top and stabilizer bar are all contacting tree.

notE: to release ratchet, simply pull the release lever and open

tightening lever wide open (flat).

Figure 1: for RE607, RE623, RE624

TREE

ratchet

back and forth

WARNING

DOuBlE ChECk AssEMBlY sTEPs TO BE CERTAIN YOu hAvE

CORRECTlY AssEMBlED ThIs PRODuCT.
sTuDY YOuR NEW sTAND TO BECOME fAMIlIAR WITh All

Of ITs fEATuREs AND DEsIGN. AT GROuND lEvEl, fOllOW-

ING PROvIDED usE INsTRuCTIONs, PRACTICE ATTAChING

sTAND TO TREE AND REMOvING sTAND fROM TREE. PRAC-

TICE sITTING, sTANDING, AND usING ThIs PRODuCT BE-

fORE ATTAChING OvERhEAD. sAvE ThEsE INsTRuCTIONs

fOR fuTuRE REfERENCE. YOu MusT AlWAYs usE ThE PRO-

vIDED full BODY hARNEss (fAll ARREsT sYsTEM) ThAT

MEETs TMA sTANDARDs WhIlE usING ThIs PRODuCT.
AlWAYs usE ThREE PEOPlE fOR sET-uP AND TAkE-DOWN.
BE ABsOluTElY suRE ThE TREE BlADE(s) ON PlATfORM

AND ThE sTABIlIZER BAR ARE CONTACTING TREE BEfORE

ClIMBING lADDER.
sTABIlIZER BAR MusT AlWAYs BE CORRECTlY AND sECuRElY

ATTAChED TO lADDER AND TREE BEfORE ClIMBING lADDER.
sOME MODEls INCluDE A MulTI-PIECE sTABIlIZER BAR

sYsTEM. BE suRE sPRING lOCk PIN GOEs ThROuGh BOTh

ThE EXTENsION TuBE AND ThE sTABIlIZER BAR.
BE CERTAIN sPRING lOCk PINs ARE lATChED sECuRElY TO

PREvENT ACCIDENTAl REMOvAl.
BE suRE YOuR DOuBlE kNOTs ARE All sECuRE ON All

ROPE CONNECTIONs.
NEvER AsCEND OR DEsCEND lADDER WIThOuT TIE-Off

ROPEs sECuRElY hOlDING lADDER TO TREE AND sTABI-

lIZER BAR sECuRElY ATTAChED. fAIluRE TO CORRECTlY

PERfORM ThEsE sTEPs CAN CAusE ThE lADDER TO COl-

lAPsE/BuCklE-OvER BACkWARDs DuRING ThE INITIAl

AsCENT TO ATTACh RATChET sTRAP REsulTING IN sERI-

Ous INJuRY OR DEATh

Figure 2

pull tail to take out slack

tightening lever

release lever

feed through slot
