34

Operator's Manual

Rivers Edge® One-Man Ladder Stands

(fOR RE632 ONlY) With cam strap now in hand, hook “S” hook
with long strap to the stabilizer bar link welded on stabilizer bar.
Secure the ladder tight so the stabilizer bar is at a right angle to the
tree. Adjust stabilizer bar length as necessary so it contacts tree. Be
absolutely sure the tree blade(s) at the top and the stabilizer bar are
all contacting tree.

Wrap the entire cam strap assembly around tree and hook the oth-
er “S” hook through opposite side of stabilizer bar link. Be sure the
entire strap is even and at the same level all around tree. Pull tail
of long strap tight to tree. This will securely attach stabilizer bar to
tree. sEE fIGuRE 3.

e.

(fOR All lADDERs) Wrap the previously attached tie-off ropes

hanging down from platform, around the back side of tree in
opposite directions of each other. Pull the ropes snug and tie them
to the ladder at the stabilizer bar height location. This ground level
ladder-to-tree attachment will prevent the ladder from pulling
away from the tree while ascending to top for final ratchet strap
attachment. The same holds true when ladder removal is necessary.

sEE fIGuRE 4a and 4b. Be absolutely sure the tree blade(s) at

the top and the stabilizer bar are all contacting tree.

3. With two people securely holding the ladder, use the three point

contact climbing method to slowly climb the ladder and carefully
keep a constant hand grip on the ladder at all times. Always lean
forward, toward tree, to keep top section tree blade(s) against the
tree. Be certain ladder bottom is firmly seated on dry, level

ground. Attach your harness tether to the tree before securing

the platform to the tree and stepping onto platform. Refer to

the full Body harness instructions included with this product.

Figure 4a: Applies to RE607

tie-off ropes

BACk vIEW Of TREE

tree blade

ratchet strap

Figure 4b: Applies to RE623, RE624, and RE632

BACk vIEW Of TREE

upper tree

blade frame

platform

tree blade

tie-off ropes

ratchet straps

WARNING

BE CERTAIN TO AlWAYs lEAN fORWARD, TOWARD ThE TREE

WhEN AsCENDING OR DEsCENDING lADDER. ATTACh YOuR

hARNEss TEThER TO ThE TREE BEfORE sECuRING ThE PlAT-

fORM TO ThE TREE AND sTEPPING ONTO ThE PlATfORM.
AlWAYs hAvE ThREE POINTs Of CONTACT WhIlE ClIMB-

ING lADDER.
BRING RATChET sTRAP(s) uP WITh YOu IN A POCkET- DO

NOT CARRY IN YOuR hANDs!
If YOuR lADDER sTAND MODEl hAs sWING-OPEN DOORs,

AlWAYs MAkE suRE DOORs ARE sECuRElY lATChED shuT

WhEN IN usE. DO NOT lEAN AGAINsT, lEAN OvER OR sIT

ON DOORs. ThEY ARE DEsIGNED fOR ENTRANCE/EXIT

DOORs ONlY. AlWAYs BE AWARE ThE DOORs CAN uN-

lATCh AND PIvOT OPEN.

TREE

pull tail of strap tight to tree

Figure 3: for RE632

WARNING

NEvER AsCEND OR DEsCEND lADDER WIThOuT TIE-Off

ROPEs sECuRElY hOlDING lADDER TO TREE AND sTABI-

lIZER BAR sECuRElY ATTAChED. fAIluRE TO CORRECTlY

PERfORM ThEsE sTEPs CAN CAusE ThE lADDER TO COl-

lAPsE/BuCklE-OvER BACkWARDs DuRING ThE INITIAl

AsCENT TO ATTACh RATChET sTRAP REsulTING IN sERI-

Ous INJuRY OR DEATh
