Reese 50024 TITAN ROUND TUBE SLIDER User Manual

Cequent performance products, inc, Instruction manual reese, Fifth wheel slider

50024N

Ŕ 7/5/11 F PCN12170

Printed in XXX

(1) Passengers side slide assembly

(2) Drivers side
slide assembly

(5) Warning label

(6) Indicator pin

(4) Cotter pin in tube

(7) Slider Tube

(4) Cotter pin

(8) Handle Grip

(4) Cotter pin in tube

(9) Straight Handle

(10) Roll Pin

PLYMOUTH, MI

(OVER)

Figure 1

(1) Provide this Manual to end user.

(2) Physically demonstrate sliding procedures in this Manual to end user.

(3) Have end user demonstrate that he/she understands procedures.

(1) Read and follow this Manual every time you use this REESE

™

Fifth Wheel Slider.

(2) Save this Manual for future reference.

(3) Pass on copies of Manual to any other user or owner of a REESE

™

Fifth Wheel Slider.

(4) Never remove Fifth Wheel Slide warning decal as shown on the cover of this manual. If damaged, contact Cequent

Performance Products, Inc. (1-888-521-0510) for free replacement decals.

DEALER/INSTALLER:

END USER:

INSTRUCTION MANUAL

REESE

™

Fifth Wheel Slider

(3) Bent
Handle

Cequent Performance Products, Inc.

NOTE: This product is rated at 20,000 lbs gross trailer wt. and 5,000 lbs vertical pin wt.
Do not exceed the tow vehicle manufactures towing rating.
Do not exceed the rating of the fifth wheel hitch you are using.

For Installation Assistance or Technical Help, call: 1-888-521-0510

NOTE: This Fifth Wheel slider will
position your Fifth Wheel hitch 11”
rearward. This HOWEVER does NOT
guarantee clearance between your truck
cab and the trailer.

ITEM

DESCRIPTION

QTY

Pasengers side assy.

Drivers side assy.

Bent Handle

Cotter pin, 1/4" x 1-1/2"

Warning label

Indicator pin, 1/4" x 2"

Slider tube

Handle Grip

Straight Handle

Roll Pin, 1/4" x 1"
