Appendix A
51 Avaya P120 SMON User Guide
Using the Find Dialog Box
Depending on the application you have initiated this option from, the
Find option allows you to locate a specific VLAN/port/LAG intersection in
the application window.
To search:
1. Click .
Or
Select Edit > Find . The Find dialog box opens.
Figure A-6. Find Dialog Box (for Ports)
The information you are prompted for in the Find dialog box
differs depending on the application from which you have initiated
it.
For more detail, refer to “Finding a Port” on page 52, “Finding a
VLAN” on page 52, or “Finding a LAG” on page 52.
2. Enter the information in the dialog box and click Find . The VLAN/
port/LAG intersection found is highlighted in the application for
easy identification.
To remove the highlight from the application window, click the graph.
The highlight disappears.
* Note: The Find button changes to Find Next until all instances of the
search information have been found.
